INFICON MPG40x ATM to Ultra-High Vacuum Gauge - Manual (Page 27)

tina48e1-b (2008-10) MPG400-401.om
27
Pos. Description Ordering number
11
12
10a Maintenance set, consisting of:
1× seal HNV 100 (9 Ч1.6)
1Ч centering ring
3× ignition aid
1× washer (not used with MPG401)
351-997
13
13a
13b
9a
10
10a
11
12 Repair set, consisting of:
1× Pirani element with glass feedthrough
1× screw fitting
1× copper seal
1× anode extension piece
1× anode, complete
3× ignition aid
1× seal
HNV 100 (9 Ч1.6)
1Ч centering ring
351-996
10a Set of ignition aids, consisting of:
10× ignition aid
351-995
Mounting tool for ignition aid 351-994
Measurement system, complete
DN 25 ISO-KF flange
DN 40 ISO-KF flange
DN 40 CF-F flange BN846472-T
BN846473-T
BN846474-T
MPG401
13a
13
13b
10
11
10a
12
9a
