3128160
– JLG Lift –
3-17
.
FIGURE 3-5. QUIK WELDER INSTALLATION (USA BUILT MACHINES PRIOR TO S/N 0200123646 &
BELGIUM BUILT MACHINES PRIOR TO S/N 1200002324)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
QUIK WELDER INSTALLATIONS Ref.
0272879 1930ES Ref. A
0272880 2030ES Ref. A
0272881 2630ES Ref. A
0272882 2646ES & 3246ES Ref. A
1 2030010 Extinguisher, Fire 1
2 2902334 Kit, Quik Welder (See Items 101 - 116 for Breakdown) 1
3 3290606 Nut (Metric) m6 x 1 6
4 4010617 Screw (Metric) 6 x 45mm 6
5 Cable, Quik Welder Power Options: 1
4923049 1930ES
4923050 2030ES
4923051 2630ES
4923052 2646ES & 3246ES
2902334 QUIK WELDER KIT Ref. A
101 0861527 Box, Welder Disconnect 1
102 1320224 Clamp 4
103 1705213 Decal - ON/OFF 1
104 1705214 Decal - Plus/Minus 1
105 1705305 Decal - Weld Lead 1
106 1705953 Decal - Weight 1
107 3290606 Nut (Metric) m6 x 1 8
108 3300048 Locknut 3/4" Conduit 2
109 4010608 Screw (Metric) 6 x 16mm 6
110 4010614 Screw (Metric) 6 x 30mm 2
111 4340860 Quik Welder Box Mounting 1
112 4360155 Switch, Master 1
113 4460328 Connector 2
114 4530021 Welder 1
115 4923048 Cable, Quik Welder Assembly 1
116 1060957 Cable, Welder 1
