SECTION 1 - SPECIFICATIONS
1-8 – JLG Sizzor – 3120826
1.9 MAJOR COMPONENT WEIGHTS 1.10 CRITICAL STABILITY WEIGHTS
DO NOT REPLACE ITEMS CRITICAL TO STABILITY WITH ITEMS
OF DIFFERENT WEIGHT OR SPECIFICATION (FOR EXAMPLE:
FILLED TIRES, ENGINE) DO NOT MODIFY UNIT IN ANY WAY TO
AFFECT STABILITY.
Table 1-5. Major Component Weights
Component Lb Kg
Fixed Platform 660 300
Platform Extension 300 136
Arm Assembly- 25 RTS (Includes
Lift Cylinder) 2403 1090
Arm Assembly- 33 RTS (Includes
Lift Cylinder) 3130 1418
Arm Assembly- 40 RTS (Includes
Lift Cylinder) 3860 1750
Chassis with Pneumatic Tires 3398 1541
Chassis with Foam Filled Tires 4102 1860
Table 1-6. Critcal Stability Weights
Component Lb Kg
Tires (Balasted Only) 295 134
Engine (Ford) 525 238
Engine (Deutz) 342 155
