3.1
Main illustration
Abb. 1:
Upright freezer - Side and front views
Fig. 1:
Upright freezer - Side and front views
1 Heated vent port
2 Door handle (lockable)
3 Control panel/display
4 Model label
5 Battery switch behind lockable panel
6 On/Off circuit breaker behind lockable panel
7 Transport castors
8 Chart recorder (optional)
9 Air filter grille
10 Quarter turn fastener
11 Specification plate
