Product Information
This monitor is E NERGY S TAR
®
compliant. A s an E NERGY S TAR
® P artner, PHILIPS has
determined that this product meets the E NERGY S TAR ® guidelines for energy efficiency.
RETURN TO TOP OF THE PAGE
Physical Specifications
• Dimension (WxHxD) * 375 x 376 x 210 mm (in lowest position)
• Weight 6 kg
• Tilt / Swivel -5° ~ 25° / + - 125°
• Height adjustment rang 70 mm
• Power supply 100 — 240 VAC, 50/60 Hz
• Power consumption 40 W* (typ.)
• Temperature
5° C to 40° C (operating)
-20° C to 60° C (storage)
• Relative humidity
20% to 80%
• System MTBF 50K hours (including CCFL 40K hours)
* This data is subject to change without notice.
* Resolution 1280x1024, standard size, brightness max., contrast 50%, 9300° K, full white pattern,
without audio/USB.
RETURN TO TOP OF THE PAGE
Pin Assignment
1. The digital only connector contains 24 signal contacts organized in three rows of eight contacts.
Signal pin assignments are listed in the following table:
Pin
No.
Signal
Assignment Pin
No.
Signal
Assignment Pin
No. Signal
Assignment
1 T.M.D.S. Data2- 9 T.M.D.S. Data1- 17 T.M.D.S. Data0-
2 T.M.D.S. Data2+ 10 T.M.D.S. Data1+ 18 T.M.D.S. Data0+
