CS48AU2B Data Sheet
Dedicated 32-bit Audio DSP for Audyssey Laboratories Technology
16 Copyright 2009 Cirrus Logic DS876F3
CONFIDENTIAL
CONFIDENTI
A
L
DRA
FT
D
ELPHI
5.11 Switching Characteristics — Serial Control Port - I
2
C Slave Mode
Figure 5. Serial Control Port - I
2
C Slave Mode Timing
Parameter Symbol Min Typical Max Units
SCP_CLK frequency
1
1. The specification f
iicck
indicates the maximum speed of the hardware. The system designer should be aware that the actual
maximum speed of the communication port may be limited by the firmware application. Flow control using the SCP_BSY pin
should be implemented to prevent overflow of the input data buffer.
f
iicck
- 400 kHz
SCP_CLK low time t
iicckl
1.25 - µs
SCP_CLK high time t
iicckh
1.25 - µs
SCP_SCK rising to SCP_SDA rising or falling for
START or STOP condition t
iicckcmd
1.25 µs
START condition to SCP_CLK falling t
iicstscl
1.25 - µs
SCP_CLK falling to STOP condition t
iicstp
2.5 - µs
Bus free time between STOP and START conditions t
iicbft
3 - µs
Setup time SCP_SDA input valid to SCP_CLK rising t
iicsu
100 ns
Hold time SCP_SDA input after SCP_CLK falling t
iich
20 - ns
SCP_CLK low to SCP_SDA out valid t
iicdov
- 18 ns
SCP_CLK falling to SCP_IRQ rising t
iicirqh
- 3
*
DCLKP + 40 ns
NAK condition to SCP_IRQ low t
iicirql
3
*
DCLKP + 20 ns
SCP_CLK rising to SCB_BSY low t
iicbsyl
- 3
*
DCLKP + 20 ns
SCP_BSY
SCP_CLK
SCP_SDA
SCP_IRQ
0 1 6 7 8 0 1 7
t
iicckl
t
iicckh
t
iicsu
t
iich
A6 A0 R/W ACK LSB
t
iicirqh t
iicirql
8
ACK MSB
t
iicstp
6
t
iiccbsyl
t
iicdov
t
iicbft
t
iicstscl
t
iicckcmd
f
iicck
t
iicckcmd
t
iicf
t
iicr
