PT-110xl, WP-110, PT-120, TP-120 - WP-110 XGA Line Transmitter 9
4.2 Installing the WP-110 XGA Line Transmitter
To install your WP-110 XGA Line Transmitter:
1. Connect the LINE OUT RJ-45 connector to the pre-installed UTP wiring in the
wall box opening that connects via UTP cabling to the LINE IN RJ-45 connector
of the PT-120 or TP-120.
2. Connect your 12V DC power supply to the POWER SUPPLY pins, taking
care that polarity is correct.
Connect the wire labeled “+” to the +12V pin, and the wire labeled “–” to the GND pin.
3. Insert the WP-110 directly into the wall box opening, and then mount the
front panel securely using the screws.
4. Connect the XGA source to the XGA IN 15-pin HD (F) connector.
4.3 Connecting the WP-110 to the TP-120
To connect the WP-110 XGA Line Transmitter to the TP-120 XGA Line Receiver,
as the example in Figure 4 illustrates, do the following:
1. On the WP-110, connect the XGA source (for example, the 15-pin HD output
from a computer’s graphics card) to the XGA INPUT 15-pin HD (F)
connector.
2. On the TP-120, connect the XGA OUT 15-pin HD (F) connector to the XGA
acceptor (for example, a monitor).
3. Connect the LINE OUTPUT RJ-45 connector on the WP-110 to the LINE IN
RJ-45 connector on the TP-120, via UTP cabling (with a range of more than
300ft (>100m)).
4. On both the WP-110 and the TP-120, connect the 12V DC power adapter to
the power socket and connect the adapter to the mains electricity.
The signal from the XGA source is transmitted via CAT 5 cable, decoded
and converted at the XGA OUT 15-pin HD (F) connector to the XGA
acceptor.
For details of the power connect feature see Section 2.4 .
5. On the TP-120, using a screwdriver to carefully rotate the trimmer, adjust the
output signal level and/or cable compensation equalization level, if required.
