Removing the LCD Bezel
1. Remove the LCD module. See “Removing the LCD Module” on page 73.
2. Remove the four upper screw caps and screws, and the six remaining lower securing screws.
3. Lift up the bezel, topside first, and remove it from the LCD Module.
Step
Size
Quantity
Screw Type
LCD Bezel
M2.5*6.5-I
(BZN(NYLOK-RED)
10
