Chapter 3 79
4. Hold the USB board by the edges and pull up to remove.
Removing the Modem Module
1. Remove the Upper Base. See “Removing the Upper Base” on page 74.
2. Disconnect the RJ-11 cable from the modem as shown.
3. Remove the two (2) securing screws.
Step Size Quantity Screw Type
Modem Module M2.0*3.0-I-NI-NYLOK 2
