Chapter 3 77
Removing the Finger Print Reader
1. Remove the Upper Base. See “Removing the Upper Base” on page 74.
2. Unlock the securing latch and disconnect the Touch Pad FFC.
3. Unlock the securing latch and disconnect the Finger Print Reader FFC.
4. Remove the three securing screws.
Step Size Quantity Screw Type
Finger Print
Reader M2.0*3.0-I-NI-NYLOK 3
