8 Chapter 1
Right View
Rear View
No. Icon Item Description
1 USB 2.0 port Connect to USB 2.0 devices (e.g. USB mouse,
USB camera).
2 Optical drive Internal optical drive; accepts CDs or DVDs.
3 Optical disk access
indicator Lights up when the optical drive is active.
4 Optical drive eject
button Ejects the optical disk from the drive.
5 Emergency eject
hole Ejects the optical drive tray when the computer is
turned off.
Note: Insert a paper clip into the emergency eject
hole to eject the optical drive tray when the
computer is off.
6 Modem (RJ-11)
port Connects to a phone line.
7 RF-in port Accepts input signals from digital TV Tuner
devices (only for certain models).
Kensington lock
slot Connects to a Kensington-compatible computer
security lock.
No. Item Description
1 Tuba The dedicated Tuba CineBass subwoofer pumps out earthshaking
movie-house audio.
2 Ventilation
slots Enable the computer to stay cool, even after prolonged use.
