Aspire Digital 6930 series - Manual (Page 123)

Chapter 3 113
Replacing the Speaker Module
Replacing the Keyboard
1. Align and replace the Speaker Module in the lower
case.
2. Reconnect the speaker cable as shown.
3. Place subwoofer module in to the lower case and replace the five securing screws.
1. Align the FFC with the connector and press the
latch down to secure.
2. Turn the keyboard over and press down to secure.
