APOLLO 120/150 III 8-148
A-2. T
HE
LCD
S FOR
APOLLO 150
The standard display used for the APOLLO 150 is either LG
15.1” TFT LCD, LM151X2 or its equivalent or a Chi Mei 15”
TFT LCD, M150X3-L01 or its equivalent.
A-2-1: 15.1” LG LM151X2
The LM151X2 is a TTL interface 15.1” TFT active matrix color
liquid display. It comprises amorphous silicon TFT attached to
each signal electrode, a driving circuit and a backlight. This
LCD has a built-in backlight with inverter. The 38 cm (15.1”)
diagonal display area contains 1024 x 768 pixels and can
display more than 262,144 colors simultaneously.
A-2-1-1 S
PECIFICATION
General specifications are summarized in the following:
I
TEM
S
PECIFICATION
Display Mode Normally white
Number of Color 262144 colors
Viewing Angle * Horizontal: 60 o (typ. Left side,
right side)
* Vertical: 45 o (typ. Up side,
Down side)
Cross talk Horizontal: 2.5%
Vertical: 2.5%
Response time 50ms(typ.)
Brightness (cd/m 2 ) 200 cd/m 2
Life time 40,000 hrs
Contrast Ratio 200:1
A-2-1-2. A
BSOLUTE
M
AXIMUM
R
ATINGS
I
TEMS
S
YMBOL
M
IN
. M
AX
. U
NIT
Power Supply Voltage V
DD
0 +3.6 V
DC
Lamp Current I
BL
- 9.0 mArms
Operating Temperature T
op
0 50 o C
Storage Temperature T
st
-20 60 o C
Note: Humidity (operation)20~90%, relative humidity
Humidity (non-operation) 5~85%
