Sony PCV-MXS20 - Manual (Page 37)

To Set Up Your Giga Pocket Personal Video Recorder System
37
To connect in STB mode (Option 2)
VHF/UHF
IN
VHF/UHF
OUT
Video cable
(supplied)
Audio cable L/R
(supplied)
TV Coaxial cables
(1-supplied)
LINE
IN
LINE
OUT
MONITOR DVI
R L
SPEAKER ------ VIDEO OUTPUT ------ VHF/UHF ------ VIDEO 1 INPUT ------ S VIDEO/VIDEO S VIDEO/VIDEO AUDIO AUDIO
VHF/UHF jack
Video cable adapter
(supplied)
Audio-OUT (L/R)
Audio-IN (L/R)
Video-IN
Video-OUT
Cable
service
access
(wall outlet)
