PowerBrick-CV User’s Manual
3.6 Specifications for PowerBrick-CV
Table 3.1: S ystem Features
Processor Intel Pentium M; supports Hyper Threading Technology; VRM 10.0
standard
Chipset Intel 855
System FSB 533/400 MHz
Memory Support Dual-Channel mode, DDR 400/333/266 DIMM up to 1GB
Video Integrated Intel Extreme Graphics 2, support 64MB DVMT
Audio Integrated AC '97, Realtek 650
Hard Disk Dual Independent ATA-100/66/33 support
Support up to 4 IDE devices on dual channel
DVR Module 4-port 120 FPS camera input
640 x 480, 640 x 240, 320 x 240 image resolution
Standard Motion - JPEG compression
Multi-screen monitoring
LAN Intel Pro 10/100 Mb Fast Ethernet
USB 2.0 Integrated 4 independent OHCI controller supporting USB 1.1 ports;
Integrated 1 EHCI controller supporting USB 2.0 ports; Dynamic connection
support to USB 2.0 or USB 1.1 devices
Hardware Monitor System, processor temperature, voltage and fan speed monitor. Auto
Thermal fan speed control
Power
Management
ACPI 1.0b compliance and OS direct power management, Wake-on event:
RTC/USB Keyboard/Modem/LAN/Keyboard/Mouse
Dimensions
7.60“ x 4.35“x 8.15“
Power 8 – 36 Volt
Table 3.2: Input/Output
15 Pin VGA 1
PS/2 / KB & Mouse 1 / 1
Parallel Port 1
Mic-in 1
Line-Out 1
Speaker 1
USB 2.0/ 1.1 3
RJ45 Fast Ethernet 1
Serial Port RS232 2 Option 3
12 V DC Power Jack 1
9
