Karcher IV 100-55 H B1 - Manual (Page 24)

– 11
Technical specifications
IV 100/55 H B1
Mains voltage V 400
Frequency Hz 3~ 50
Power W 6000
Maximum allowed net impedance Ohm 0.128+j0.080
Container capacity l 90
Air quantity l/s 61
Under-pressure
* with pressure limiting valve kPa (mbar) 21,0 (210)
Filter surface M filter (pocket filter) m
2
1,8
Filter surface H filter (filter cartridge) m 2 2,1
Ignition protection class
II 3D 116 °C
Protective class -- I
Type of protection -- IP54
Suction hose connection Nominal
width 50
Length of the suction hose m 5
Length x width x height mm 1220 x 670 x 1530
Typical operating weight kg 155
Ambient temperature °C -10...+40
Relative air humidity % 30...90
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 79
Uncertainty K
pA
dB(A) 1
Hand-arm vibration value m/s 2 <2,5
Uncertainty K m/s 2 0,2
Power cord H07RN-F 4x2,5 mm 2
Part no.: Cable length
EU 6.649-369.0 8 m
24 EN
