1. TUBE ROUTING
The following table is a guide on how to establish connections between the different elements of the cooling circuit, based on multiple possible
configurations:
Devices: (1) Water-block + (1) Radiator + Pump + F&B
kit
Fill & bleed
discharge
serial to
pump inlet
Pump
discharge
serial to
CPU water-
block inlet CPU
water-block
discharge
serial to
radiator
inlet Radiator
discharge
serial to fill
& bleed
inlet –
Loop
completed
Devices: (1) Water-block + VGA cooler + (1) Radiator + Pump + F&B kit
Fill & bleed
discharge
serial to
pump inlet
Pump
discharge
serial to
CPU water-
block inlet CPU
water-block
discharge
serial to
VGA cooler
inlet VGA cooler
discharge
serial to
radiator
inlet Radiator
discharge
serial to fill
& bleed
inlet –
Loop
completed
Devices: (1) Water-block + VGA cooler + Chipset cooler + (1) Radiator + Pump + F&B
kit
Fill & bleed
discharge
serial to
pump inlet
Pump
discharge
serial to
CPU water-
block inlet CPU
water-block
discharge
serial to
chipset
cooler inlet Chipset
cooler
discharge
serial to
VGA cooler
inlet VGA cooler
discharge
serial to
radiator
inlet Radiator
discharge
serial to fill
& bleed
inlet –
Loop
completed
Devices: (1) Water-block + VGA Cooler + Chipset Cooler + (2) Radiators + Pump + F&B kit
Fill & bleed
discharge
serial to
pump inlet
Pump
discharge
serial to
CPU water-
block inlet CPU
water-block
discharge
serial to
chipset
cooler inlet Chipset
cooler
discharge
serial to
VGA cooler
inlet VGA cooler
discharge
to Y
connector
for
PARALLEL
connection
to both
radiator
inlets Dual
Radiator
discharges
to Y
connector
to fill &
bleed inlet
– Loop
completed
Devices: (2) Water-blocks + VGA cooler + Chipset cooler + (2) Radiators + Pump + F&B kit
Fill & bleed
discharge
serial to
pump inlet
Pump
discharge
serial to
CPU water-
block #1
inlet CPU
water-block
#1
discharge
serial to
CPU
water-block
#2 inlet CPU
water-block
#2
discharge
serial to
chipset
cooler inlet Chipset
cooler
discharge
serial to
VGA cooler
inlet VGA cooler
discharge
to Y
connector
for
PARALLEL
connection
to both
radiator
inlets Dual
Radiator
discharges
to Y
connector
to fill &
bleed inlet
– Loop
completed
1.
Installation of the cooling components
