EN - English - I
nstruc
tions manual
4
To adjust the receivers, see the corresponding user’s
manual.
The box rack can also be powered at 24Vac using the
appropriate terminal, if the older model of receiver
that cannot be powered at 12Vdc is being used. In
this case it is necessary to obtain a 24Vac - 40VA
power supply.
Fig. 01 Back view.
7 Disposal of waste
materials
n This symbol mark and recycle system
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
8 Technical data
8.1 Mechanical
Dimensions (WxHxL): 483x134x226mm / 12.2x3.4x5.7in
(19inx3U/84TE)
Unit weight: 2.5kg / 5.5lb (3.9kg / 8.6lb, rack complete
with 14 TWRR2)
8.2 Electrical
Power supply: 12/24Vac
Consumption: 30W
Wide range power supply supplied: IN 100-240Vac -
OUT 12Vdc, 47/63Hz, 2A (supplied with 3 main supply
connecting cables)
8.3 Environment
Indoor
5 Preparing the product
for use
h Any change that is not expressly approved
by the manufacturer will invalidate the
guarantee.
5.1 Contents and unpacking
When the product is delivered, make sure that the
package is intact and that there are no signs that it
has been dropped or scratched.
If there are obvious signs of damage, contact the
supplier immediately.
Keep the packaging in case you need to send the
product for repairs.
Check the contents to make sure they correspond
with the list of materials as below:
• 1 assembled box rack with back panel
• 28 board guides
• 13 blind front panels
• 1 wide range power supply
• Instructions manual
5.2 Safely disposing of
packaging material
The packaging material can all be recycled. The
installer technician will be responsible for separating
the material for disposal, and in any case for
compliance with the legislation in force where the
device is to be used.
Bear in mind that if the material has to be returned
due to a fault, using the original packaging for its
transport is strongly recommended.
6 Configuration
6.1 Connections
Insert the TWRR2 receivers in their respective slots,
assembling the board guides (up to a maximum of 14
receivers per box). Assemble the blind front panels in
the positions that are not occupied by receivers.
Connect the coaxial cables coming from the monitors
to the BNC connectors on the back panel.
Connect the twisted pairs coming from the
transmitters to the terminals indicated by A and B the
back panel. Insert the power supply jack.
