Dee Zee DZ16223 User Manual
Page 11
Insert the 7/32" Allen through the hole drilled in Step 7 and into the head of the button head bolt.
Pull down on the mounting bracket to put the threaded plate under tension and tighten the bolt.
13
TIGHTEN BOLT
HERE WITH 7/32"
ALLEN
PULL
BRACE
DOWN
KEEP THE
BRACKET CLOSE
TO THE PINCH
WELD.
DZ 16223
9 OF 15
8/9/2013
