INSTALLATION AND OPERATION INSTRUCTIONS
INTRODUCTION
Thank you for purchasing your American Fibertek MTM-1 multimode mini video
transmitter. Please take a few minutes to read these installation instructions in order to
obtain the maximum performance from this product.
FUNCTIONAL DESCRIPTION
The MTM-1 operates as half of a transmitter / receiver pair for the transmission of
baseband NTSC, PAL, RS170, or RS343 video signals over a single multimode fiber
optic cable. It is designed to operate with the MRM-100, RRM-100, or RRM-30 video
receiver. The RRM-30 contains the electronics and optics of three RRM-100 units
mounted on one printed circuit board to save space and reduce cost.
The MTM-1 converts a single video input into a single FM modulated optical output
using an 850 nm wavelength source. The M-1, M-100, and M-30 Series product is
designed to operate over an optical loss budget range of 0 to 12 dB. The MTM-1
operates on 50 um or 62.5 um multimode fiber. Refer to the data sheets for detailed
performance specifications.
The small size and light weight of the MTM-1 allows for direct mounting on the back of a
camera in an enclosure. For a wall mounted version please see the MTM-100. For a
rack mounted version please see the RTM-100 or RTM-30.
