A14
ENGLISH
Select an input signal.
Press the SOURCE button on the remote control to select the input signal.
Or, press the SOURCE button at the front side of the product.
SOURCE SET
SOURCE SELECT
When connecting with an RCA cable.
• Select AV.
When connecting with an S-Video cable.
• Select S-Video.
B
A
When connecting with a S-Video cable.
• Connect to the S-Video input terminal to watch high image quality movies.
Connect the video cable as shown in the below figure and then connect the power
cord (See page A11).
B
When connecting with a RCA cable.
• Connect the input terminal with a proper color match.
(Video – Yellow, Sound (left) – White, Sound (right) – Red)
A
RCA Cable
(not included)
Red
White Yellow
R W Y
Product
VCR/DVD Receiver
S-Video Cable
(not included)
When watching VCR / DVD
