RFVolt2000A
Sensor Type Voltage Sensing Circuitry
Response Time 150 mS at Sensor
Measurement Range
-3 VDC to +3 VDC for 2.5 V
-8 VDC to +24 VDC for 15 V
-8 VDC to +32 VDC for 30 V
-160 mVDC to +160 mVDC for 160 mV
Measurement
Resolution
2.5 VDC (0.1 mVDC)
15 VDC (0.5 mVDC)
30 VDC (1.0 mVDC)
160 mVDC (5 µV)
Measurement
RF Frequency
2.45 GHz IEEE 802.15.4 ultra-low power wireless transceiver
with fully bi-directional communication
Band
ISM band 2.405-2.475 GHz
Operation (channels 11 through 25) @ 250 kbps
Maximum Output
Power
+0 dBm typical
Receiver Sensitivity
(RFC1000)
-95 dBm typical
Transmission Distance
(to other RFC1000’s)
• RFC1000
4,000 ft max. outdoors - line of sight unobstructed
1,000 ft max. indoors - typical urban environment
• RFC1000-CE
2,500 ft max. outdoors - line of sight unobstructed
700 ft max. indoors - typical urban environment
• RFC1000-IP69K
4,000 ft max. outdoors - line of sight unobstructed
1,000 ft max. indoors - typical urban environment
Transmission Distance
(to data loggers)
• RFC1000, RFC1000-CE & RFC1000-IP69K
2,000 ft max. outdoors - line of sight unobstructed
500 ft max. indoors - typical urban environment
Wireless
Battery Warning
WARNING: BATTERY MAY LEAK, FLAME OR EXPLODE IF DISASSEMBLED, SHORTED, CHARGED, CONNECTED
TOGETHER, MIXED WITH USED OR OTHER BATTERIES, AND/OR EXPOSED TO FIRE/HIGH TEMPERATURE.
DISCARD USED BATTERY PROMPTLY, KEEP OUT OF REACH OF CHILDREN.
Specifications subject to change.
See MadgeTech’s terms and conditions at www.madgetech.com
7
