6
TECHNICAL DATA
20
GA24
www.krohne.com 02/2011 - 4001229901 MA GA24 R01 en
6.2 Technical data
INFORMATION!
•
The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local representative.
• Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Download Center).
Measuring system
Application range Flow measurement of liquids, gases and vapors
Operating method / measuring principle Variable area measuring principle
Measured value Measured value Measured value Measured value
Primary measured value Float position
Secondary measured value Operating and standard volumetric flow
Measuring accuracy Measuring accuracy Measuring accuracy Measuring accuracy
Directive VDI / VDE 3513, sheet 2 (q
G
=50%)
Measuring accuracy 1.o%
Operating conditions
Temperature Temperature Temperature Temperature
Max. operating temperature TS -40...+120°C / -40...+248°F
Pressure Pressure Pressure Pressure
Max. permitted operating gauge pressure PS at TS
= 100°C
Pressure equipment directive 97/23/EC
Test pressure PT Pressure equipment directive 97/23/EC or
AD 2000-HP30
DN15, DN25 10 bar 1
DN40 9 bar 1
DN50 7 bar 1
Installation conditions
Inlet condition, run ≥ 5 x DN
Outlet condition, run ≥ 3 x DN
1 other pressures upon request
