DESCRIPTION. The Kepco Model CA 34-R RoHS-compliant Cover (see Figure 1) is supplied for use with Kepco
Series RKW 50 Watt power supplies. The cover is installed by first removing one screw (M3 X 8) from the RKW power
supply (see Figure 1). Then slide the cover onto the power supply, matching the tabs as shown in Detail A, and secure
with screw previously removed. This screw must not be overtightened (max. torque 10 in.- lbs (1.1 N x m). See Figure
2 for outline dimensions.
FIGURE 1. CA 34-R COVER INSTALLATION
RKW TAB
RKW 50W POWER SUPPLY
CA 34 COVER
REMOVE EXISTING SCREW (M3 x 8) FROM
RKW POWER SUPPLY AND USE TO SECURE
COVER TO POWER SUPPLY.
MAX TORQUE 10 1N.-LBS (1.1N x m)
RKW TAB
3042541
SEE DETAIL A
SEE DETAIL A
COVER TAB
COVER TAB
DETAIL A
