D De ettc co onn M Mo od de ell 997722--004411117700--0000LL
Gas Detection System
Operator's Instruction Manual
August 1, 1998 Document #2051 Rev 1.0
Detcon Model 972-041170-00L gas detection system consists of 2 major assemblies:
1. The NEMA 4 fiberglass sample draw enclosure.
2. The remote mount gas sensor assemblies.
The NEMA 4 fiberglass sample draw enclosure is detailed in section 1 of this manual. The remote mount
gas sensor assemblies are detailed in the attached sensor manual(s).
detcon inc.
0
100
200
300
400
500
CAL PORT
SET
FLOW
SAMPLE
PORT
detcon inc. HOUSTON, TEXAS
SAMPLE DRAW
GAS DETECTION SYSTEM
ON/OFF
FLOW FAULT
POWER
