Page 6

ODEL

RT2000 (X2) I

NSTALLATION

UIDE

EMPERATURE

/ H

UMIDITY

1. The ATM will operate over a range of tem-

peratures and humidity. Generally, these
parameters must fall within the following
ranges:

EDICATED

ELEPHONE

3. Ensure the following telephone-line require-

ments are met:

Dedicated line. The telephone line servicing the
ATM will not be a “party” line or any other shared
type connection.

Proximity to Interference Sources. The

t e l e -

phone line must not be in close proximity to “noisy”
devices that could induce interference into the ATM
communications channel. See the next section for
additional information on “interference sources.”

RF I

NTERFERENCE

Ensure there are no devices near the termi-

nal that may cause RF interference, such as:

TVs

Coolers

Security devices

Neon signs

Devices with compressors

* IMPORTANT *

AC power for the terminal should come from
a dedicated source with an isolated ground.

Dedicated source. The ATM AC power feed will be
a dedicated line, to which no other electrical devices
are connected. The ATM power line will be wired for
a single “duplex”-style outlet and connected directly
to the AC service panel.

Isolated Ground. An equipment grounding conduc-
tor that is insulated from the conduit or raceway and
all other grounding points throughout its entire length.
The only points of electrical connection will be at
the duplex outlet and service panel ends of the line.

AC P

OWER

EQUIREMENTS

2. Ensure the following AC power requirements

are met:

Current (Max)

5.05A @ 115 VRMS at 60 Hz

2.01A @ 230 VRMS at 50 Hz

Voltage

9506 # +]

Power Consumption (Idle)

$ # 9$& DW +]

Power Consumption (Max Load)

:DWWV # 9$&

Temperature (Exterior)

& WR &

) WR )

Relative Humidity

When installing an ATM, some general environmental and power precautions need to be con-
sidered. Evaluate the location where the ATM will be installed. To help ensure proper operation
of the ATM, ensure the environmental criteria listed are met.

Temperature (Interior)

& WR &

) WR )

Relative Humidity

1RQ&RQGHQVLQJ
