TM

Triangle engineering of arkansas, inc.

E-mail: [email protected] • Website: www.trianglefans.com
1101 N. Redmond Road • Jacksonville, AR 72076 • (501) 982-7558 • Fax (501) 982-5691 • 1-800-255-9014

PROblEM:

1. Shutter does not close completely

2. Shutter does not open when starting fan in

low speed, but does open when starting fan in

high speed.

3. After attempting Solution #2, shutter still

closes on low speed.

4. Shutter apparently operates properly with the

exception that it develops a rattle while in the

semi-open position.

SOlUTION:

1. Spring has too much tension. Remove end of

spring from tie bar and place in holes closer

to spring post, to reduce tension, and allow

shutter to close properly.

2. Fan should always be turned on high speed

first then to low speed, should that be the

desired operating speed. By going thru this

procedure, shutter should quickly open and

remain open during low speed operation.

3. You may find it necessary to move the spring

on the tie bar away from the spring post

another hole which will tighten the spring.

4. Increase the exhaust area for air to escape

from the attic.

clEANING INSTRUcTIONS:

CLEAN PAINTED SHUTTERS WITH MILD DETERGENT.

2/07
