Hardware features
1
Part# : FTLX8511D3-F1 , Serial#: KCP02X8
Port 2/2:
Type : 10GBASE-SR/SW (XFP)
Vendor: FOUNDRY NETWORKS, Version: 02
Part# : TRF2000EN-LF251 , Serial#: T07J23170
All show media done
Syntax: show media
Power supplies
Each device comes with one alternating-current (AC) or one direct-current (DC) power supply. All
models have two power supply slots, enabling you to install a second power supply for redundancy.
NOTE
Changes or modifications made to this device that are not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
The power supplies can be swapped in or out of the device while the device is running. You can
remove and insert a power supply without opening the chassis. The remaining supply provides
enough power for the entire system.
The following sections provide further details about the power supplies for the devices:
• Power status LEDs are listed in “Observing the power status LEDs” on page 47.
• Hardware specifications for the power supplies are listed in “Hardware specifications” on
page 59.
• “About redundant power supplies and power supply failure” on page 22
AC power supplies
Figure 33 shows a rear view of a device containing one AC power supply.
FIGURE 33 AC Power Supply
1 Power supply
2 Six cooling fans
