PAGE 7
OWNER’S MANUAL
SIREN ICON- This icon indicates that the alarm has been triggered.
The remote will start to beep and the siren icon will come on solid at
the same time as the icon for the violated zone.
A N T E N N A I C O N- This icon will be visible or show a series of
lines next to the icon whenever the remote is within transmitting
range of the vehicle. The icon will disappear when out of
transmitting range.
STATUS ICONS
These icons display the current status of the system. The icons may not all be
present on the screen at all times, certain icons will only turn on when a feature
is activated.
STATUS CHECK MODE
This feature is used to check the status of the system. To check the status
press and release the button on the remote transmitter. The remote will
display the icons of the active features on the LCD screen.
TRUNK ICON- This icon will be displayed on the LCD screen when
the trunk release is activated. The icon will stay displayed until the
system is armed or if the status button is pressed.
BATTERY ICON- This icon is always present to indicate the
current battery level of the remote transmitter. The black area of the
icon will disappear as the battery level decreases.
NOTE: For best performance change battery when 2 bars down.
(see page 12 Transmitters)
STATUS BAR- This icon is active at all times. The bar graph will
scan back and fourth (every 10 seconds), to check the status of the
system. The speed will increase when the alarm is triggered.
LCD Display
(660 & 670)
