TABLE 1
SUGGESTED BLADE SPEEDS
BLADE
DIAMETER
OPTIMUM
RPM
MAX SAFE
RPM
(D-P
BLADES)
GPM
3.80
CU IN
MOTOR
GPM
5.20
CU IN
MOTOR
18” 2100 3400 30
24” 1600 2500 26
30” 1300 2000 21
36” 1100 1700 18 24
42” 900 1400 16 20
48” 800 1200 13 18
54” 700 1100 11 16
HYDRAULIC SYSTEM
Your CC1600 wall saw is designed to operate from a separate hydraulic power unit
providing up to 30 gpm at 2500 psi (up to 129 l/min at 172 bar). See blade speed table
above for flow requirements with a specific blade/motor combination.
MAXIMUM CUTTING DEPTH
The CC1600 saw will cut to within 2 3/4” of the blade center. For example, a 36”
blade has a radius of 18”. The maximum depth of cut is 18” - 2 3/4” = 15 1/4”.
TABLE 2
MAXIMUM CUTTING DEPTH
BLADE DIAMETER MAXIMUM CUTTING DEPTH
18” 6.3”
24” 9.3”
30” 12.3”
36” 15.3”
42” 18.3”
48” 21.3”
54” 24.3”
