CSB Battery XTV12950 User Manual
12v 95ah, Powered by

6
12
95 Ah @ 10hr-rate to 1.80 V per cell
Approx. 32.8 kg(72.31 lbs)
800A(5sec)
Approx. 3.8mΩ
13.5 to 13.8 VDC/unit Average at
28.5A
14.4 to 15.0 VDC/unit Average at
CSB Batteries can be stored for more than 6 months at
25°C(77°F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Discharge:
Charge:
Storage:
I2-Thread lead alloy recessed terminal to accept M6/M8 bolt
PP (UL 94-HB) & Flammability resistance
of (UL 94-V0) can be available upon request.
Cells Per Unit
Voltage Per Unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
XTV 12950 is a general battery up to 12 years expected life in
standby service or more than 260 cycles at 100% discharge in
cycle service . XTV has a wider operating temperature range,
which makes them more suitable for the systems in harsh
conditions.
Constant Current Discharge Characteristics Unit:A (25°C,77°F)
XTV12950
12V 95Ah
Specification
Powered by
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
216.4±2.5 (8.52±0.10)
213.9±2.5 (8.42±0.08)
343.0±2.5 (13.50±0.10) 170.0±2.0 (6.69±0.08)
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
The system of manufacturer was certified
by TUV CERT according to ISO 9001,ISO 14001.
Constant Power Discharge Characteristics Unit:W (25°C,77°F)
@25°C (77°F)
25°C (77°F)
25°C (77°F)
-20°C~50°C (-4°F~122°F)
-20°C~50°C (-4°F~122°F)
-15°C~40°C ( 5°F~104°F)
25°C±3°C (77°F±5°F)
F.V/Time
5MIN
10MIN
15MIN
30MIN
60MIN
90MIN
2HR
3HR
5HR
8HR
10HR
20HR
1.60V
361
250
191
116
69.2
51.0
41.1
28.3
17.9
11.9
10.0
5.18
1.67V
319
233
182
114
67.8
49.9
40.2
28.0
17.7
11.8
9.79
5.15
1.70V
298
223
177
112
67.0
49.5
39.9
27.6
17.6
11.7
9.72
5.13
1.75V
264
206
169
107
65.1
48.0
38.7
26.9
17.4
11.6
9.59
5.07
1.80V
240
186
156
101
62.7
46.1
37.0
26.4
17.0
11.4
9.50
4.98
1.85V
198
166
136
92.4
58.5
43.1
34.7
25.0
16.3
11.0
9.05
4.79
F.V/Time
5MIN
10MIN
15MIN
30MIN
1HR
90MIN
2HR
3HR
5HR
8HR
10HR
20HR
1.60V
3383
2525
2032
1258
768
567
457
324
209
140
117
60.7
1.67V
3128
2400
1972
1244
757
559
451
321
207
139
116
60.0
1.70V
3021
2330
1950
1232
755
556
448
318
206
138
115
59.7
1.75V
2833
2186
1829
1193
739
543
437
310
204
136
114
59.4
1.80V
2496
2029
1675
1137
713
522
419
304
198
134
113
58.5
1.85V
2124
1804
1476
1056
672
495
398
289
189
129
108
56.8
RA1403
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
