ABUS TVIP515x0 - Manual (Page 90)

90
English
5.1 Audio / video control
These functions are only available when using Internet Explorer.
Snapshot
The web browser displays a new window containing the snapshot. To save the snapshot, either left-click it
and then click the floppy disk icon or right-click it and select “Save” from the context menu.
Full-screen
Activates the full-screen view. The live image on the network camera is shown on the entire screen.
Start / stop live image
The live stream can be stopped (paused) or exited. In both cases, the live stream can be continued by
pressing the Play symbol.
Local recording
A recording on the local hard disk can be started or stopped here. By clicking the button, the Windows “Save
as” dialog is called up.
Select a storage folder on your hard disk. A directory and recording file are created automatically in the folder
under the following name:
YYYYMMDD
YYYYMMDDHHmmss.avi
Y = Year
M = Month
D = Day
H = Hour
m = Minute
s = Second
