1-3 Chapter 1: General information
(continued on the next page)
I/O
Display 1 x HDMI port
1 x VGA port
Audio 3 Audio jack (Line-in, Mic-in, Line-out)
LAN 2 x LAN (RJ-45) ports
Serial Port 1 x RS-232/422/485 supports 5V/12V/RI option (COM1, D-Sub 9)
1 x RS-232 (COM2, D-Sub 9)
PS/2 Port 1 x PS/2 Keyboard port
1 x PS/2 Mouse port
FAN 1 x 4-pin CPU Fan connector
1 x 4-pin Chassis Fan connector
ENVIRONMENT & POWER & ME
Battery
Lithium battery
Power Requirement 1 x 24-pin ATX connector
1 x 4-pin ATX 12V power connector
Power Compliance
EuP/ErP compliant
Operating
Temperature
32~140 o F (0~60 o C)
Operating Humidity
0%~90%RH, non-condensing
Certificate
CE & FCC
Form Factor
Mini ITX form factor: 6.7 in x 6.7 in (170 mm x 170 mm)
Weight
1.1 lb (05. kg)
PLACEMENT
Rear panel ports 1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x HDMI port
1 x VGA port
2 x LAN (RJ-45) ports
2 x COM ports
4 x USB 3.0 ports
3 x Audio jacks
