Extron Electronics YCS SW2 User Guide User Manual
Page 15

YCS SW2 • Installation and Operation
Installation and Operation, cont’d
2-16
YCS SW2
A
Appendix A
Specifi cations, Part Numbers,
and Accessories
Specifi cations
Included Parts
Accessories
Selecting an Input by Using the Buttons
The YCS SW2 has two inputs available — one composite
video and one S-video. You can select either of these inputs by
pressing the appropriate button on the front panel. When an
input is selected, its LED lights and remains lit while its input
source is active.
The front panel buttons are labeled “1” and “2” for the two
inputs. Press input button 1 to select the composite video input,
or button 2 to select the S-video input.
You can also set up the YCS to select inputs via contact closure
or autoswitching. For information on enabling input selection
by either of these methods, see Contact closure or Autoswitching,
earlier in this chapter.
The YCS SW2 does not have non-volatile memory.
Therefore, the input selection defaults to input 1 after a
power loss.
