Command
ASCII Command
(Host to Device)
Response
(Device to Host)
Additional Description
EDID
NOTE: Digital EDID can be assigned only to a digital input. Analog EDID can be assigned only analog input 1.
Input EDID (VGA and HDMI)
Assign factory EDID
E
A
X1!
*
X2&
EDID
}
EdidA
X1!
*
X2&]
Set the EDID resolution and
refresh for input
X1!
.
View assigned EDID
E
A
X1!
EDID
}
X2&]
View EDID resolution and refresh
for input
X1!
.
Save EDID
E
S
X1%
EDID
}
EdidS
X1%]
Save VGA loop-through or HDMI
switched output EDID to user
location
X1%
.
View EDID native
resolution
E
N
X1!
EDID
}
X@]
View native resolution.
View current EDID in Hex
E
R
X1!
EDID
}
X#]
View EDID in Hex format.
Export EDID selection
E
E
X2&
EDID
}
X$
Export EDID in binary format.
Import EDID
E
I
X1$
EDID
}X$
EdidI
X1$]
Import EDID in binary format to
user stored EDID slot
X1$
.
Advanced Configurations
Input sync detection (VGA only)
View input sync detection
E
1LS
}
xxx.x,xxx.x
]
Shows horizontal frequency in
kHz and vertical frequency in Hz.
Returns
000.0,000.0
if no signal
is detected.
Input video format (VGA only)
Set input video format
1*
X1^
\
Typ1*
X1^]
Sets input 1 to format
X1^
.
View input video format
1\
X1^]
View input 1 video format.
NOTE:
X@
= Native resolution and refresh rate
X#
= EDID record (Hex)
128 or 256 bytes
X$
= EDID record (binary)
128 or 256 bytes
X1!
= Input selection
1
= VGA (input 1)
2
= HDMI (input 2)
3
= HDMI (input 3)
X1$
= User assigned EDID
55
= VGA user assigned input 1
56
= HDMI user assigned input 2
57
= HDMI user assigned input 3
X1%
= Save EDID
58
= VGA loop-thru output EDID
59
= HDMI switched output EDID 1
60
= HDMI switched output EDID 2
61
= HDMI switched output EDID 3
62
= HDMI switched output EDID 4
X1^
= Input video format
0
= auto detect (default)
1
= RGB
2
= YUV
X2&
= EDID output resolution See the tables on page 14.
