Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Supply Voltage 2.5 to 5.5 V
Operation Temperature Range -40 to +85
°C
Junction Temperature Range -40 to +125
Thermal Information
Parameter Package Symbol Max Unit
Thermal Resistance (Junction to Case) TSOT25 (Note 1) θ
JC
130
°C/W
Thermal Resistance (Junction to Ambient) TSOT25 θ
JA
250
Internal Power Dissipation TSOT25 P
D
400 mW
Note: 1. The maximun output current for TSOT25 package is limited by internal power dissipation capacity as described in
Application Information here inafter.
