APX809/810
3-PIN MICROPROCESSOR RESET CIRCUITS
APX809/810 Rev. 4 2 of 9 FEBRUARY 2009
www.diodes.com © Diodes Incorporated
( Top View )
1
2 GND
V
CC
2
3
(RESET) RESET
( Top View )
1
2
GND
(RESET)
V
CC
APX809
APX810
2
3
RESET
SOT23R SOT23
APX809
APX810
Absolute Maximum Ratings
Symbol Parameter Rating Unit
ESD HBM Human Body Model ESD Protection 5 KV
ESD MM Machine Model ESD Protection 500 V
V
CC
Supply Voltage -0.3 to +6.0 V
V
RESET
RESET, RESET (push-pull) -0.3 to (V
CC
+ 0.3) V
I
CC
Input Current, V
CC
20 mA
I
O
Output Current, RESET, RESET 20 mA
P
D
Continuous Power Dissipation (T
A
= +70°C),
de-rate 4mW/°C above +70°C
400 mW
T
OP
Operating Junction Temperature Range -40 to +105 °C
T
ST
Storage Temperature Range -65 to +150 °C
Pin Assignments
Pin Descriptions
Pin Name Description
GND Ground
RESET
(RESET)
Reset Output Pin
L: for APX809
H: for APX810
V
CC
Operating Voltage Input
