AL3159

HIGH EFFICIENCY 1x/2x CHARGE PUMP

FOR WHITE LED APPLICATIONS

AL3159

Document number: DS35048 Rev. 2 - 2

7 of 10

January 2011

NEW PROD

Ordering Information

Package

FS : QFN3030-20

AL 3159 FS G - 7

Packing

7 : Tape & Reel

Green

G : Green

Device

Package

Code

Packaging

(Note 7 and 8)

7” Tape and Reel

Quantity

Part Number Suffix

AL3159FSG-7

QFN3030-20

3000/Tape & Reel

-7

Notes:

7. Pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which can be found on our website at

http://www.diodes.com/datasheets/ap02001.pdf

8. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at

Marking Information

(1) QFN3030-20

(Top View)

Y : Year : 0~9

X : A~Z : Green

XX : B9 : AL3159

W : Week : A~Z : 1~26 week;

a~z : 27~52 week; z represents

52 and 53 week

Part Number

Package

Identification Code

AL3159FSG QFN3030-20
