1-22 Chapter 1: Hardware information
1.8.4 PCI slots
The PCI slots support cards such as
a LAN card, SCSI card, USB card, and
other cards that comply with PCI
specifications. The figure shows a
LAN card installed on a PCI slot.
1.8.6 PCI Express x16 slot
This motherboard supports PCI
Express x16 graphic cards that
comply with the PCI Express
specifications. The figure shows a
graphics card installed on the PCI
Express x16 slot.
1.8.5 AGP slot
The Accelerated Graphics Port (AGP) slot supports AGP8X cards. When you
buy an AGP card, make sure that you ask for one with +1.5V specification.
Note the notches on the card golden fingers to ensure that they fit the
AGP slot on your motherboard.
Install only 1.5 V or 0.8 V AGP cards on this motherboard!
Below:Mic In Center:Line Out Top:Line In
P5VDC-X
R
Keyed for 1.5v
P5VDC-X Accelerated Graphics Port (AGP)
The PCI Express x 16 slot runs at x 4 speed max.
