Knowing the Parts
<000>
Rear Side
Refer to the diagram below to identify the components on this side of the Notebook PC.
HDMI
7 1 2 3 4 5 6
1
2
3
4
Cooling Fan
The cooling fan removes excess heat depending on temperature threshold settings.
IMPORTANT! Make sure that paper, books, clothing, cables, or other objects
do not block any of the air vents or else overheating may occur.
Kensington ® Lock Port
The Kensington ® lock port allows the Notebook PC to be secured using Kensington ® com-
patible Notebook PC security products. These security products usually include a metal
cable and lock that prevent the Notebook PC to be removed from a fixed object.
Some may also include a motion detector to sound an alarm when moved.
TV-Out Port
The TV-Out port is an S-Video connector that allows routing the Notebook PC’s display
to a television or video projection device. You can choose between simultaneously or
single display. Use an S-Video cable (not provided) for high quality displays or use the
provided RCA to S-Video adapter for standard video devices. This port supports both
NTSC and PAL formats.
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard VGA-compatible device such as a monitor
or projector to allow viewing on a larger external display.
5 HDMI Port
HDMI (High-Definition Multimedia Interface) is an uncompressed all-digital audio/
video interface between any audio/video source, such as a set-top box, DVD player,
and A/V receiver and an audio and/or video monitor, such as a digital television
(DTV). Supports standard, enhanced, or high-definition video, plus multi-channel
digital audio on a single cable. It transmits all ATSC HDTV standards and supports 8-
channel digital audio, with bandwidth to spare to accommodate future enhancements or requirements.
