2.5.4

Hardware Monitor

The items in this sub-menu displays the hardware monitor values
automatically detected by the BIOS. It also allows you to change CPU Q-Fan
feature-related parameters. Select an item then press to display
the configuration options.

F1:Help

↑

↑↓

↓

↓ : Select Item

-/+: Change Value

F5: Setup Defaults

ESC: Exit

→←

→←: Select Menu

Enter: Select Sub-menu

F10: Save and Exit

Select Menu

Item Specific Help

Press [Enter] to
enable or disable

Hardware Monitor

Q-Fan Controller

[

Disabled

]

Vcore Voltage

1.56V

3.3V Voltage

3.18V

5V Voltage

5.05V

12V Voltage

11.58V

CPU Temperature

48ºC

M/B Temperature

41ºC

CPU FAN Speed

3068 RPM

Chassis Fan Speed

0 RPM

CHIP FAN Speed

7758 RPM

x CPU Target Temperature

72ºC

CPU Fan Speed warning

[1200 RPM]

Chassis Fan Speed warning

[Disabled]

CHIP Fan Speed warning

[Enabled]

Phoenix-Award BIOS CMOS Setup Utility

Power

Q-Fan Controller [Disabled]

Allows you to enable or disable the Q-Fan controller.
Configuration options: [Disabled] [Enabled]

Vcore Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage

The onboard hardware monitor automatically detects the voltage output
through the onboard voltage regulators. These items are not
user-configurable.

CPU Temperature, M/B Temperature

The onboard hardware monitor automatically detects and displays the
motherboard and CPU temperatures. These items are not user-configurable.

CPU Fan Speed [xxxxRPM]

CPU Fan Speed [xxxxRPM]
Chassis Fan Speed [xxxxRPM]

Chassis Fan Speed [xxxxRPM]

Chassis Fan Speed [xxxxRPM]
CHIP Fan Speed [xxxxRPM]

CHIP Fan Speed [xxxxRPM]

The onboard hardware monitor automatically detects and displays the CPU,
Chassis, and chip fan speeds in rotations per minute (RPM). If any of the
fans is not connected to the motherboard, the field shows 0. These items
are not user-configurable.
