2.4.2
2.4.2
2.4.2
2.4.2
2.4.2
CPU Configuration
CPU Configuration
CPU Configuration
CPU Configuration
CPU Configuration
Select Menu
Item Specific Help
DRAM timing and
control
CPU Configuration
CPU Type
AMD Athlon(tm) 64 Processor 3200+
CPU Speed
2000MHz
Cache RAM
1024K
DRAM Configuration
Hyper Transport Frequency
[4x]
AMD K8 Cool’n’Quiet control
[Disabled]
Phoenix-Award BIOS CMOS Setup Utility
Advanced
DRAM Configuration
DRAM Configuration
DRAM Configuration
DRAM Configuration
DRAM Configuration
The items in this sub-menu show the DRAM-related information
auto-detected by the BIOS.
Select Menu
Item Specific Help
configuration by [Auto]
is recommended.
[Manual] allows you to
set each configuration on
your own.
DRAM Configuration
Timing Mode
[
Auto
]
x Memclock index value (Mhz)
166Mhz
x CAS# latency (Tcl)
2.5
x Min RAS# active time(Tras)
7T
x RAS# to CAS# delay (Trcd)
3T
x Row precharge Time (Trp)
3T
x 1T/2T Memory Timing
1T
S/W DRAM Over 4G Remapping
[Enabled]
Phoenix-Award BIOS CMOS Setup Utility
Advanced
Timing Mode [Auto]
Sets the timing mode. Configuration options: [Auto] [Manual]
The following items are user-configurable only when the Timimg Mode
item is set to [Manual].
Memclock index value (Mhz) [166Mhz]
Sets the memory clock index value.
Configuration options: [100Mhz] [133Mhz] [166Mhz] [200Mhz]
CAS# latency (Tcl) [2.5]
Sets the CAS# latency.
Configuration options: [2] [2.5] [3]
Min RAS# active time (Tras) [7T]
Sets the minimum RAS# active time.
Configuration options: [5T] [6T] [7T] [8T] [9T] [10T] [11T] [12T]
[13T] [14T] [15T]
