GE Industrial Solutions Austin Microlynx II SMT - Manual (Page 21)

Data Sheet
September 10, 2013 Austin MicroLynx TM II SMT Non-isolated Power Modules:
2.4 – 5.5Vdc input; 0.75Vdc to 3.63Vdc Output; 6A output current
LINEAGE POWER 21
Document No: DS03-107 ver. 1.05
PDF name: microlynx_II_smt_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
Efficiency
3.3V@ 6A
On/Off
Logic
Connector
Type
Comcodes
ATH006A0X-SR 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% Negative SMT 108988358
ATH006A0X-SRZ 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% Negative SMT CC109104535
ATH006A0X4-SR 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% Positive SMT 108988366
ATH006A0X4-SRZ 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% Positive SMT 108996708
-Z refers to RoHS compliant parts
