52
PowerVac ® 5kV Vertical Lift
Renewal Parts
Location of nameplates in Type AM Magne-blast Vertical Lift Lineup
Shown below is a typical switchgear lineup.......
Figure 50. Schematic of ML-19 Mechanism
g GE PowerVac Breaker
Type VBI 4.16 - 250
Ser. No. 0357A4157-001-03
Rated Max
Voltage
5 KV Rated Amp. 1200 HZ 60 Withstand 60 KV 5 CYC
Rated Short Rated Voltage
Circuit Amps 29
Close
Coil
0282A73406002 Volts 125 DC
Trip Coil -1 0282A70156006 Volts 125 DC
Trip Coil -2 Volts Tripping Amps
Charging Motor 0177C50506001 Volts
Connector Diagram 020988250P002 Wt. 470 LBS. Mech.Type ML-18 Date Mfg.4/99
Vac. Inter. Type 50F Req: 625-1222W
Caution Before Installing Or
Operating Read Instr. DEH 40012
GE
Industrial Systems
W. Burlington, IA 52655 USA
SO: 977673
Impulse
Range Factor 1.24 KA
125VDC` HZ
Closing
Amps 6.0
Volt
Range
100-140
Volt
Range
Volt
Range
70-140
Close & Latch
Capability Amp
60 KA
