INSTALLATION
This antenna should be mounted on the car roof to ensure best
omnidirectional coverage. The antenna is provided with our type ZG-mount
for mounting from the outside in a 21 mm dia. hole.
The ZG-mount is provided with an M8 x 1 thread mount system. This
construction meets the demand for a low-profile mobile mount with a slim
appearance and with protection against theft of the antenna whip.
When cleaning the car in automatic washing machines, the whip is easily
removed using a spanner, size 12 mm. The whip is refitted again by
screwing it onto the M8 x 1 thread stud and tightening it with the spanner.
1. INSTALLATION DIMENSIONS
2. INSTALLATION STEPS
3. TUNING
The antenna is delivered factory-tuned and requires no further tuning.
PROCOM A/S reserve the right to amend specifications
without prior notice.
16/12/11
