B&B Electronics ExpressCard Serial Adapter User’s Manual Using configuration utilities
Rev 1.00 (July 2007) Page 23
Figure 23 - Windows XP Device Manager - Serial Port, Driver tab
Step7,l/. Procedure Description

Step 13 You have several options:
 View detailed driver information
 Update the device drivers
 Uninstall your Serial Adapter.
 Return to the previously installed
driver. (XP only)
 Save your changes and exit.
 Abandon your changes and return to
the Device Manager.
See below.
Don’t use this option. Uninstall the
entire device instead by using the Driver
dialog for the multiport serial adapter.

Step 14 Click the Driver Details button to view
detailed driver information.
The Driver File Details dialog box opens.
See the following figure.
Figure 23 illustrates the Serial
Port, Driver Tab, which lets
you view the driver details and
update, roll back, or uninstall
the driver.
