B&B Electronics ExpressCard Serial Adapter User’s Manual Using configuration utilities
Rev 1.00 (July 2007) Page 21
Figure 21 - Windows XP Device Manager - Serial Port, Port settings tab
Step Procedure Description

Step 9 This Port Settings tab allows you to set
default values for the following:
 Bits per second
 Data bits
 Parity
 Stop bits
 Flow control
Most applications do not make use of
these default settings, but prefer to make
their own settings.
See the Setting advanced options section
for details.

Step 10 Press the Advanced button. The Advanced Options dialog box opens.
Figure 21 illustrates the Serial
Port, Port Settings Tab.
