B&B Electronics ExpressCard Serial Adapter User’s Manual Using configuration utilities
Rev 1.00 (July 2007) Page 19
Step Procedure Description

Step 4 The ExpressCard Serial Port Advanced
Options Tab allows you to force a clock
multiplier to increase the effective
maximum data rate with some legacy
applications. The clock rate will be
applied to all serial ports on the card
Additional RS-422/485 Advanced Option
Settings are available for each individual
port and will allow you to set the
connector signals selection and the duplex
mode, and receiver control.
See the Setting advanced options section
for details.

Step 5 Click Cancel to close the property box.

Step 6 With Device Manager open, expand the
Ports (COM & LPT) device group.
The ports associated with the Serial
Adapter should appear in the list of
ports.

Step 7 Double click the desired port. The ExpressCard Serial Port Properties
dialog box opens and displays the
General tab.

Step 8 Click the Port settings tab. The Port Settings dialog box displays.
