17
ATF1502AS(L)
0995J–PLD–09/02
SUPPLY CURRENT VS. SUPPLY VOLTAGE
AS VERSION (T
A
= 25°C, F = 0)
0
10
20
30
40
50
60
70
4.5 4.75 5 5.25 5.5
V
CC
(V)
I CC
(m
A
) STANDARD POWER
REDUCED POWER
SUPPLY CURRENT VS. SUPPLY VOLTAGE
PIN-CONTROLLED POWER-DOWN MODE (T
A
= 25°C, F = 0)
0
2
4
6
8
10
12
14
4.5 4.75 5 5.25 5.5
V CC (V)
I CC
(m
A
)
TBD
SUPPLY CURRENT VS. FREQUENCY
AS VERSION (T
A
= 25°C)
0.0
10.0
20.0
30.0
40.0
50.0
60.0
0.00 20.00 40.00 60.00 80.00 100.00
FREQUENCY (MHz)
I CC
(m
A
)
STANDARD POWER
REDUCED POWER
OUTPUT SOURCE CURRENT VS. SUPPLY VOLTAGE
(V
OH
= 2.4V, T
A
= 25°C)
-60.0
-50.0
-40.0
-30.0
-20.0
-10.0
0.0
4.50 4.75 5.00 5.25 5.50
SUPPLY VOLTAGE (V)
I OH
(m
A
)
SUPPLY CURRENT VS. SUPPLY VOLTAGE
(T = 25°C, NON-TURBO, BIT6 = 0, BIT 30 = 0)
0.0
20.0
40.0
60.0
80.0
100.0
120.0
4.00 4.50 4.75 5.00 5.25 5.50 6.00
VCC (V)
I CC
(µ
A
)
SUPPLY CURRENT VS. FREQUENCY
ASL (LOW-POWER) VERSION (T
A
= 25°C)
0.0
10.0
20.0
30.0
40.0
50.0
60.0
0.00 10.00 20.00 30.00 40.00 50.00
FREQUENCY (MHz)
I CC
(m
A
)
STANDARD POWER
REDUCED POWER
OUTPUT SOURCE CURRENT VS. OUTPUT VOLTAGE
(V
CC
= 5V, T
A
= 25°C)
-100.0
-90.0
-80.0
-70.0
-60.0
-50.0
-40.0
-30.0
-20.0
-10.0
0.0
0.00 0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 4.50 5.00
OUTPUT VOLTAGE (V)
IO
H
(mA
)
