MAX5383/MAX5384/MAX5385

Low-Cost, Low-Power, 8-Bit DACs with 3-Wire
Serial Interface in SOT23

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(V

DD

= +2.7V to +3.6V (MAX5383), V

DD

= +4.5V to +5.5V (MAX5384), V

DD

= +2.7V to +5.5V (MAX5385), R

L

= 10k

Ω, C

L

= 50pF,

T

A

= T

MIN

to T

MAX

, unless otherwise noted. Typical values are T

A

= +25°C.)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

V

DD

to GND ..............................................................-0.3V to +6V

OUT ............................................................-0.3V to (V

DD

+ 0.3V)

CS, SCLK, DIN to GND ............................................-0.3V to +6V
Maximum Current into Any Pin............................................50mA
Continuous Power Dissipation (T

A

= +70°C)

6-Pin SOT23 (derate 8.7mW/°C above +70°C)..........696mW

Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Maximum Junction Temperature .....................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

STATIC ACCURACY

Resolution

8

Bits

Integral Linearity Error

INL

(Note 1)

±1

LSB

Differential Linearity Error

DNL

Guaranteed monotonic

±1

LSB

Offset Error

V

OS

(Note 2)

±1

±25

mV

Offset Error Supply Rejection

MAX5385 (Notes 2, 3)

60

dB

MAX5383/MAX5384

3

Offset Error Temperature
Coefficient

MAX5385

1

ppm/

°C

M AX 5383/M AX 5384

10

Full-Scale Error

C ode = 255, no l oad

MAX5385

5

% of

i d eal FS

Full-Scale Error Supply
Rejection

C od e = 255 ( N ote 4)

M AX 5383/M AX 5384

50

dB

M AX 5383/M AX 5384

±40

Full-Scale Error Temperature
Coefficient

Code = 255

MAX5385

±10

ppm/

°C

DAC OUTPUT

MAX5383

1.8

2

2.2

MAX5384

3.6

4

4.4

Internal Reference Voltage
(Note 5)

REF

MAX5385

0.85

×

V

DD

0.9

×

V

DD

0.95

×

V

DD

V

Code = 255, 0

µA to 100µA

0.5

Output Load Regulation

Code = 0, 0

µA to 100µA

0.5

LSB

[D13, D12] = 0, 1

1k

[D13, D12] = 1, 0

100k

Shutdown Output Resistance
to GND

V

OUT

= 0 to V

DD

[D13, D12] = 1, 1

1M

DYNAMIC PERFORMANCE

Voltage Output Slew Rate

Positive and negative

0.4

V/

µs

Output Settling Time

To 1/2 LSB, 50k

Ω and 50pF load (Note 6)

20

µs

Digital Feedthrough

Code = 0, all digital inputs from 0 to V

DD

2

nVs
